L-Series with LED Strobes
L-Series and L-Series with LED Specifications
Physical/Electrical Specifications
Standard Operating Temperature : 32°F to 120°F (0°C to 49°C)
Humidity Range : 10 to 93% non-condensing
Strobe Flash Rate : 1 flash per second
Nominal Voltage, LED Strobes and Horn Strobes : Regulated 24 VDC
Operating Voltage Range, LED Strobes and Horn Strobes : 16 to 33 V (24 V nominal)
Operating Voltage Range, Horns : 8 to 17.5 V (12 V nominal) or 16 to 33 V (24 V nominal)
Input Terminal Wire Gauge : 12 to 18 AWG
L-Series with LED Dimensions: Wall-Mounted Equipment
