Specification
1.Wireless sending distance(open area) : inset antenna 150m.
2.Working frequency : 433MHz
3.Working voltage : 3V lithium battery
4.Current : static ≤10uA, alarm : ≤35mA
5.Alarm output : Police intelligence report,
Recovery Report, tamper report, Low battery report with a status report.
6.Tips : Police report, recovery report, tamper report
Low battery voltage report, status report.
7.Status Report : Initial power-up or reset of the transmitter after
the operation, door Send a working status report to the host every 2K.
8.Working temperature : -10°C ~ +50°C
9.Dimension : 69.5(L)*21.2(W)*19.5(H)mm
Magnetic stripe : 34.5(L)*10(W)*13.2(H)mm
10.Color : White
