Suitable gas types: town gas
Closing modes: current impulse or manual
Body: wrought brass alloy(HPb59-1)
Driving Voltage: DC 9 ~12 V (Impulse)
Sealing material: NBR rubber
Driving current: 1000μf capacitor discharge
Operation temperature: -10 ~ +50 ℃
Closing time: < 1 sec
Pressure max: 20kPa or 100kPa
Explosion proof mark: ExmⅡT6
Connection: G1/2”, G3/4” female thread
Lead wire: 0.4m
Turn on: manual
Standard: Q/TDBX01-2007, GB3836.9-2000
